Liquid Penetrant Testing (PT) Method - Level I and II

COURSE DESCRIPTION

This course is designed to meet the industrial qualification requirements for Penetrant Examination. This method is used to locate surface discontinuities in non-porous materials. This examination is used to locate discontinuities including inherent, processing, and service defects. The training covers written instructions used by the employer and interpretation of indications. The course satisfies the training hours required for both Level 1 and Level 2 certification in accordance with SNT-TC-1A , CP-189 and NAS-410.

Course Duration: 32 Total Hours

Prerequisite: High school physics and algebra helpful but not required.


COURSE OUTLINE

1. PERSONNEL REQUIREMENTS

2. BASIC THEORY | FUNDAMENTALS | TECHNICAL THEORY | METHOD

  • Definitions

  • Penetrating Ability

  • Contact Angle

  • Capillary Action

  • Process

  • Cleaning, surfaces (pre and post cleaning)

  • Penetrant Systems: (Types, Processing Methods, Sensitivity Levels)

  • Application Methods

  • Dwell Times / Factors in Dwell Time

  • Penetrant Removal

  • Emulsifiers: (Lipophilic, Hydrophilic)

  • Drying

  • Developers: (Dry, Wet Aqueous, Nonaqueous)

  • Light Intensities

  • Types of Indications

  • Testing Principles, including choice of NDT methods, relevance to different materials and part and test variables

  • Product Forms and Materials; Defect Formation and Characterization

  • Equipment Operation and Standardization

  • Importance of Process Controls

  • Importance of Appropriate Processing Steps and Parameters

  • Safety

  • Applicable Techniques and the Advantages and Disadvantages of Each

  • Limitations and Capabilities of Each Method and Technique

3. APPLICABLE SPECIFICATIONS | CODES | OPERATING PROCEDURES AND WORK INSTRUCTIONS

4. HANDS-ON INSPECTION OF ACTUAL PARTS

5. SAMPLE EXAMS | REVIEW

6. ACTUAL EXAMS

7. TRAINING REFERENCES

  • Nondestructive Testing Handbook, Vol. 2, 3rd Edition, ISBN 1-57117-028-6

  • Liquid Penetrant Testing: Classroom Training Handbook, Duane Badger, ISBN 1-57117-121-5

  • Metals Handbook, Nondestructive Inspection and Quality Control, Vol. 17, 9th Edition, published by ASM International

  • Annual Book of ASTM Standards; Vol. 03.03, Nondestructive Testing, published by ASTM International


REGISTRATION

Class size is limited. This allows for maximum utilization of course time,
hands on instruction, and equipment.
